Yes. RayNeo lists Xbox among the gaming consoles that connect to AR display glasses like the RayNeo GT Max through its HDMI Adapter. Xbox hardware sends video out over HDMI, and GT Max expects a USB-C video signal instead, so the adapter is what bridges the two rather than a direct cable.
For most Xbox players, GT Max is the better fit of RayNeo’s two AR glasses. It has the larger virtual screen (a 267-inch cinema display, with 227-inch and 307-inch sizes also available), a wider 59-degree field of view, and three IPD size options (S/M/L) chosen at checkout. The RayNeo GT covers the same connection path at a lower $299 price point, with a smaller screen and a fixed 64mm IPD.
RayNeo’s GT series glasses connect to phones, tablets, and laptops over USB-C using DisplayPort Alt Mode, a standard that sends video, not just power, through a USB-C cable. Xbox hardware doesn’t have that; it sends video out through an HDMI port instead, which is why RayNeo’s compatibility list places Xbox under HDMI Devices rather than USB-C devices.
That mismatch is normal. Most game consoles and TVs still run on HDMI, while USB-C video output is mostly found on newer phones, tablets, and some laptops. It’s not a limitation specific to RayNeo’s glasses or to Xbox. It’s just two different video standards that need a translator between them.
That translator is the RayNeo HDMI Adapter, priced at $64 at the time of writing, which brings the glasses-and-adapter subtotal for getting an Xbox running on GT Max to $463, or $363 for GT. Both totals assume a USB-C PD power source is already on hand; the adapter needs one to run, and it isn’t included.
RayNeo’s product listing describes the adapter’s job as converting the HDMI signal from the Xbox into the USB-C connection the glasses expect. If nothing shows up after everything is connected, the product page’s no-signal troubleshooting guidance is the first thing to check.
Power works differently here than it does when a phone or laptop connects directly to GT Max or GT. In that direct USB-C setup, RayNeo says the connected device powers the glasses and processes the video, which is why slight warmth and higher battery use on that device are normal. An Xbox connected through the HDMI Adapter doesn’t power the glasses the same way, which is why the adapter itself needs its own USB-C PD power source to stay properly powered.
The spec sheet matters less than what it changes about the picture. GT Max centers on a 267-inch virtual cinema screen, with 227-inch and 307-inch sizes also available, viewed through a 59-degree field of view on a 1920x1080 Micro-OLED panel. In practice, that’s closer to sitting in front of a large projector screen than staring at a phone-sized display floating in front of your eyes.
The panel runs at 120Hz in 2D mode. That’s a panel spec rather than a measurement of what the adapter passes through from an Xbox signal specifically, but a 120Hz panel is generally suited to keeping fast camera pans and quick UI transitions smoother than lower-refresh mobile displays typically manage. Contrast is rated at 200,000:1 with 98% DCI-P3 color coverage, specs that are generally associated with deeper shadow detail and more accurate color in darker scenes. What is confirmed is the connection itself: the HDMI Adapter converts the Xbox’s HDMI signal into the USB-C connection the glasses expect over a wired path, and the panel runs at 120Hz.
Audio runs through a Bang & Olufsen-tuned four-speaker array with spatial sound and head-tracked audio, features built to place directional cues (footsteps, gunfire, an engine approaching from one side) in the direction they’re supposed to come from rather than a single flat channel.
For seating position, GT Max offers three spatial modes. Follow “keeps the screen centered as you move your head,” RayNeo’s own description for casual, on-the-move viewing. Steady offers “stable viewing with subtle natural movement,” suited to travel and commuting where the ride itself is bumpy. Pinned “keeps the screen fixed in one position,” built for focused, cinema-like viewing, and it’s the mode most Xbox players will reach for during couch sessions since the screen stays put instead of tracking every head turn away from the controller.
GT Max uses open-ear speakers rather than sealed earbuds, so sound isn’t fully private by default. RayNeo’s own guidance is that audio becomes difficult to make out from roughly 1.5 meters away, though someone standing close by may still hear some of it.
Whisper Mode is built for situations like a late Xbox session while someone else in the room is asleep. RayNeo describes it as a way to “reduce audio leakage in quiet or public environments.” It can be turned on with a long press on the volume rocker, which cycles through Standard, Whisper, and Spatial Surround, or through the RayNeo XR App under Glasses Settings > Whisper Mode.
Both models connect to Xbox through the same RayNeo HDMI Adapter and share the same listed display, refresh-rate, and audio specifications. The differences come down to screen size, field of view, weight, and fit.
| RayNeo GT Max | RayNeo GT | |
|---|---|---|
| Price (at time of writing) | $399 | $299 |
| Field of view | 59° | 46° |
| Pixel density | 38 PPD | 49 PPD |
| Virtual screen sizes | 227” / 267” / 307” | 136” / 201” / 231” |
| Weight | 78g | 68g |
| IPD fit | Three sizes: S / M / L | Fixed 64mm |
| Refresh rate | 120Hz (2D) / 60Hz (3D) | 120Hz (2D) / 60Hz (3D) |
| Audio | B&O four-speaker, Whisper Mode | B&O four-speaker, Whisper Mode |
GT Max is the stronger match for most Xbox setups. The wider field of view and larger 267-inch screen option make more of a difference on console gaming, where the picture is the main event, and the S/M/L IPD sizing means more people can order a size that fits without relying on nose pad adjustments alone. RayNeo publishes an IPD measurement tool at ipd.rayneo.com for anyone unsure which size to order. Including the adapter, the glasses-and-adapter subtotal for a full Xbox setup on GT Max runs $463 ($399 plus the $64 HDMI Adapter), plus a USB-C PD charger if one isn’t already on hand.
GT is the option worth considering for a lighter frame and a lower price, particularly if a quick check against that IPD tool shows a fit close to 64mm; with the adapter, the glasses-and-adapter subtotal on GT is $363, again before any additional USB-C PD charger needed. GT’s narrower 46-degree field of view feels more like a large flat-panel TV positioned across the room, rather than GT Max’s wraparound view, though text and menus are likely to look sharper on GT thanks to its higher 49 PPD pixel density versus GT Max’s 38 PPD. Anyone who wants the largest available screen size for Xbox should lean toward GT Max, and GT Max also offers more IPD size options if a closer, more personalized fit matters.
The RayNeo HDMI Adapter isn’t Xbox-specific. RayNeo’s compatibility list also groups PS4, PS5, and Nintendo Switch under the same HDMI Devices category, supported through the same adapter. Anyone gaming across an Xbox and a PlayStation, or an Xbox and a Switch, only needs the one $64 adapter rather than a separate accessory per console.
RayNeo confirms Dolby Vision playback when GT Max or GT are paired with the Pocket TV Pro streaming device and the content itself is Dolby Vision. These product pages don’t confirm Dolby Vision for an Xbox connected through the HDMI Adapter; that pairing is described specifically around Pocket TV Pro’s Google TV streaming apps.
GT Max’s Tech Specs list AI HDR as a supported capability. RayNeo’s own wording, from the same section that covers the Pocket TV Pro pairing, reads: “Paired with RayNeo Pocket TV Pro, GT Max delivers an immersive Dolby Vision experience. AI real-time SDR-to-HDR conversion is supported across all compatible devices.” RayNeo doesn’t spell out which devices count as “compatible” for that second sentence, so it isn’t clear whether an Xbox signal passing through the HDMI Adapter falls inside that set. For Xbox specifically, GT Max’s baseline specs, 200,000:1 contrast and 98% DCI-P3 color coverage, are the numbers to judge the picture on.
Does GT Max work with Xbox?
Do I need the Pocket TV Pro to play Xbox games on GT Max?
Does the RayNeo HDMI Adapter need its own power source?
Can I skip the HDMI Adapter by playing on my phone instead?
Why doesn’t Xbox get the same Dolby Vision support as Pocket TV Pro?
For most people asking whether Xbox works with smart glasses, GT Max is the model built for it: the larger screen, wider field of view, and S/M/L IPD sizing make it the more complete console-gaming setup, and it uses the same $64 HDMI Adapter RayNeo lists for other HDMI consoles. GT is the option for anyone who wants the same connection path at a lower price and a lighter frame, provided the fixed 64mm IPD lines up with their measurements.
